DIGIMAX Semi-Automatic compression-flexural cement testers

ASTM C109 | ASTM C349 | ASTM C348 | EN 196-1

MAIN FEATURES

• Dual user interface display and PC
• Accuracy Class 1 (EN) and Class A (ASTM) starting from 10% of full scale.
• Compatible with the new, intuitive and smart DATA MANAGER Software. Very easy to use, complete with many functions, totally flexible, open to network comunications
• Double stage hydraulic pump with rapid approach and precise oil flow control. Allowing high throughput of accurate tests (up to 40 per hour)
• Optional internal graphic printer including Load-Time plot
• Connect to laboratory network via LAN port/software
• Allow remote verification of settings and performances. For easy debugging of unexpected malfunctions
• Recording facility of up to 10 test profiles for each channel allowing quick and easy test start



GENERAL DESCRIPTION

Frames
These machines, featuring a very rigid two column frame, have been designed for the testing of the cement prism either in compression or in flexure.

Two versions are available:

65-L28B0x models, double testing chamber, 15/300 kN  cap., fitted with round platens for testing in compression and flexion cement, mortar, resins and other materials.
Conforming to EN 196-1, 1015-11, ASTM C109, C348, C349 using the suitable accessories.

65-L18B0x models, 300 kN cap., fitted with round platens for testing cement, mortar, resins and other materials and other materials.
Conforming to  EN 196-1, 1015-11, ASTM C109, C349 using the suitable accessories.

All models are fitted with pressure transducer/s for load measurement and have a vertical span of 200 mm hence can house all standard accessories for cement and mortar testing (see accessories) and furthermore can be used to test other specimens directly on the standard compression platens adjusting, if necessary, the vertical daylight, with the suitable distance pieces (see accessories). Compression platens can be supplied complete with Platen surface hardness certificate. See upgrading options.

Digimax redout unit

Hardware
132,000 points effective resolution, three channels, touch screen graphic display 240x128 pixel, sampling rate 50/sec, large storing capacity on USB pen drive, test data downloadable to PC, Ethernet port, real time management software (optional, see accessories 82-SW/DM DATAMANAGER)

Firmware
Simultaneous display of load-specific load, actual load rate and load/time graph; LAN connection to PC; advanced memory management; multi coefficient calibration.
Recording facility of up to 10 test profiles for each channel including type of test (e.g. compression, flexural, indirect tensile), specimen size and shape, load rate, standard in use and other general informa¬tion. Each one of the recorded test profile can be recalled automatically to save time

Safety features
Includes: Max. pressure valve to avoid machine overloading; piston travel limit switch; emergency stop button; front door and rear transparent fragment guard on request, see Upgrading Options.


ORDERING INFORMATION

300kN compression testers

65-L18B02
300 kN cap., automatic compression tester for cement, mortar, resins and other materials using the suitable accessory. Load measurement by pressure transducer. DIGIMAX readout unit. Round compression platens 165 mm dia. 230 V, 50 Hz, 1 ph.
65-L18B03
Same as above but 220 V, 60 Hz, 1 ph
65-L18B04
Same as above but 110 V, 60 Hz, 1 ph


300kN/15kN compression testers

65-L28B02
Double chamber automatic compression tester, 15/300 kN cap., for cement, mortar, resins and other materials using the suitable accessory. Load measurement by pressure transducers. DIGIMAX readout unit. Round compression platens 165 mm dia. 230 V, 50 Hz, 1 ph.
65-L28B03
Same as above but 220 V, 60 Hz, 1 ph
65-L28B04
Same as above but 110 V, 60 Hz, 1 ph

ACCESSORIES

Compression devices for cement and mortars
Flexural test devices for mortar beams
Distance pieces to adjust the vertical daylight
Data manager PC software

UPGRADING

Graphic printer (To be factory installed)
50-C10/PR
Upgrading the DIGIMAX, PILOT and AUTOMAX to incorporate a serial graphic printer in the front panel allowing also load/time plot at the end of test.
Specifications:
- Very silent printing
- High speed: 50 mm/sec
- High resolution: 203 dpi=8 dots/mm
- Support test and graphic printing
- Easier maintenance with self-diagnostic
- Paper width: 57.5 mm

Safety fragment guard
65-L1800/P
Transparent rigid fragment guard for  65-L18xxx compression testers and frames
65-L2800/P
Transparent rigid  fragment guard for 65-L28xxx compression testers and frames

Platens surface hardness certificate
50-L0050/HRD
Traceable hardness certificate for platens 165 mm dia. Min. hardness 55,5 HRC.
Available only for ordering with the machine
